| No. | Characteristic | Reference Standard | Unit | Comparision for extruded samples | ||
| KAXITE PA66GF | KAXITE Improved PVC | Normal UPVC | ||||
| 1 | Dimension (Width 25mm) Tolerance range | mm | ±0.05 | ±0.05 | ±0.1 | |
| 2 | Chemistry Characteristic | Non-toxic | Non-toxic | Toxic | ||
| 3 | Working Temperature | EN ISO 11357-3 | ℃ | <250 | <220 | <70 |
| 4 | Density | EN ISO 1183-1 or -3 | g/cm3 | 1.30±0.05 | 1.30±0.05 | 1.55±0.05 |
| 5 | Annealing Residue (glass fiber content) | EN ISO 1172 | % | 25±2.5 | 25±2.5 | 25±2.5 |
| 6 | Shore Hardness D | EN ISO 868 | - | 82±4 | 82±4 | 82±4 |
| 7 | Impact Strength | EN ISO 179-13) DIN 53453 4) | KJ/m2 | ≥50 or without break | ≥30 or without break | ≥10 or without break |
| 8 | Tensile Strength | EN ISO 527-2 and -4 | N/mm2 | ≥80 | ≥60 | ≥30 |
| 9 | Young's Modulus | EN ISO 527-2 and -4 | N/mm2 | ≥4500 | ≥3500 | ≥1000 |
| 10 | Elongation at Break | EN ISO 527-2 and -4 | % | ≥3 | ≥3 | ≥3 |
| 11 | Life | Years | > 30 | > 20 | > 5 | |
